 | Product Discontinues. Call us at 888-483-2418 for replace items.
KVM on the NET
ATEN's new KVM on the NET, CN5000, is an IP implemented KVM solution that allows network administrators to access computers from any station connected to the network, whether from the LAN, WAN, or the Internet. Network administrators can enjoy freedom from being bound to the server room; work from anywhere in the office, remote locations, or even from home! Since KVM on the NET uses TCP/IP as its communication protocol, network administrators can remotely access attached KVM switches, allowing remote control of the attached servers to perform many tasks with ease and speed, such as installing and running GUI applications, BIOS level troubleshooting, routine monitoring, system maintenance, system administration, and rebooting. It supports 10Base-T, 100Base-T, TCP/IP, and HTTP through the Java Client. The server can be accessed whether it is down the hall, on the other side of town, or thousands of miles away! Utilizing advanced security technologies, KVM on the NET provides password protection, advanced encryption technologies, sophisticated user filters user management, Radius server, stealth mode and automatic lockout to make sure that remote access is secure. This unit allows you to create up to 64 users, and 16 of them can login silmultaneously. Also, KVM on the NET offers high resolution (up to 1600 x 1200 @ 60Hz), user-friendly Windows GUI Client Software and Java client software.
Features
- Remotely control your servers via the LAN, WAN, or the Internet
- Supports 10Base-T, 100Base-T, TCP/IP, and HTTP through the Java Client
- Support Radius servers
- Works with most KVM switches
- Create up to 64 users
- Allows up to 16 users for silmutaneous login
- One price - all software included
- Sophisticated Administrator software allows setup for network, security, and user management
- Advanced security features: password protection, advanced encryption technologies, sophisticated user filters and user management, stealth mode and automatic lockout, and Radius server
- User-friendly client software allows for video adjustment, bandwidth control and mouse synchronization
- High video resolution: up to 1600 x 1200 @ 60Hz
- Windows GUI and Java based client software; Java client works with all operating systems
- Upgradeable firmware
- Designed for both desktop and rack mount (rack mount kit included)
Requirements
- PIII 1 GHz or faster processor
- For the Windows Client, you must have DirectDraw 7.0 or higher installed.
- The Windows Administrator Utility software, the Windows Client software, the Log Server, and the Java Client software all support Windows 9x, ME, 2000, and XP. Java Client software supports various other operating systems, such as Mac, Solaris, and Linux, etc.
For the computer to be accessed by CN5000: Mouse settings for various operating systems are as follows:
- For Windows XP, set the mouse speed to the middle position and disable Enhance Pointer Precision
- For Windows 2000, set the mouse speed to the middle position, and select None for mouse acceleration
- For Windows NT/98, set the mouse speed to the slowest position
- For Windows ME, set the mouse to the middle position, and disable mouse acceleration.
- For Redhat Linux, set the mouse threshold to the middle position, and mouse acceleration to the middle position
Package Content:
- 1 x CN5000 unit 1
- x Software CD
- 1 x Power Adapter
- 1 x PS/2 KVM Cable
- 1 x Rack Mount Bracket
- 1 x Quick start guide
- 1 x User Manual
 |
Specification
: |
 |
|
 |
| Case |
|
| Width |
11.7
in. (29.8 cm.) |
| Height |
9.5
in. (24 cm.) |
| Length |
20
in. (50.8 cm.) |
| Case
Qty. |
5 |
| Package
Dimensions |
|
| Width |
10.5
in. (26.7 cm.) |
| Depth |
8.8
in. (22.2 cm.) |
| Height |
3.8
in. (9.5 cm.) |
| LEDs |
|
| 10/100
Mbps |
1xOrange/Green |
| Link |
1xGreen |
| Power
On |
1xOrange |
| Console
Connectors |
|
| Mouse |
1x6
in mini-DIN Female (PS/2) |
| Monitor |
1xHDB-15
Female |
| Keyboard |
1x6
in mini-DIN Female (PS/2) |
| Housing |
|
| Case |
Metal |
| Weight |
|
| Case
Wt. |
15.4
lbs. (7 kg.) |
| Package
Wt. |
1
lbs. (1.5 kg.) |
| Unit
Wt. |
3.3
lbs. (0.5 kg.) |
| Dimensions |
|
| Depth |
3.2
in. (8.1 cm.) |
| Width |
8
in. (20.3 cm.) |
| Height |
1
in. (2.5 cm.) |
| CPU
Connectors |
|
| Keyboard, Mouse, and Monitor |
1 x SPHD-15 Female |
| Maximum
color bit depth output |
15 |
| Protocols |
10Base-T Ethernet; 100Base-T Fast Ethernet; TCP/IP |
| Encryption |
SSL2.0, SSL3.0 and TLS1.0 protocol |
| LAN
Connection |
1xRJ-45
Female |
| Video
Resolution |
Up to
1600 x 1200 @ 60Hz |
| Reset
Switch |
1xMomentary
Switch |
| Storage Temperature |
-4~140F (-20C~60C) |
| Operating Temperature |
32F~122F (0C~50C) |
| Security |
Authentication, Radius server, IP/MAC filter, user management, automatic lockout |
|
|
|
|
This product has a limited warranty of:
12 months for parts and 12 months for labor.
This warranty is provided by Aten Technology. www.aten-usa.com
Support Phone Number: 888-999-aten
