6.5" Open Frame LCD Monitor (Model: FOP6500A)

Overview
Download

Perfect for small footprint applications, iTech's FOP6500A, 6.5" Open Frame LCD Monitor is available with a 800 nit LCD panel that shines in either indoor or outdoor environments. The miniscule open frame form factor is a space saver and gives your application designer freedom to build all types of enclosure models. Take solace in our open frame monitor enclosure design as it will never change even when a new generation of LCD panels is introduced. Once you design in the monitor, the open frame enclosure will remain consistent throughout the lifetime of the product.

The FOP6500A, 6.5" open frame monitor has been used in projects such as instrumentation panel displays, small form kiosks, photo booths and even ATM machines. The sturdy steel housing is milled from a CNC machine and maintains high quality throughout the whole process.

FOP6500A Open Frame Monitor Quick Facts

4:3 Aspect, 640 x 480 resolution
High grade TFT, 800 nit LCD Panel
Standard 15-pin VGA input connector
DVI, Composite and BNC video input options

Standard Features

Compatible with iTech's standard definition signage players
Robust ventilation structure
Compliant with RoHS, UL, CSA, TUV, FCC B, VCCI B, CE TCO 99, TUV Ergo, EPA Energy Star
Perfect for kiosk, equipment and instrument drop-in designs
Superior viewing angles, contrast ratio and brightness
DVI Composite and BNC video input options
Durable Resistive and Surface Acoustic Wave Touchscreen options

Included in the package

FOP6500A, 6.5" Open Frame LCD Monitor
+12V power adapter and cord
VGA cable

Specifications

Model	FOP6500A
LCD Panel
Display Panel	6.5 inch TFT LCD
Dot Pitch	0.207(H) x 0.207(V) mm
Max. Resolution	640 x 480 VGA
Contrast Ratio	600:1 (typical)
Brightness	800 cd/m2 (typical)
Uniformity	80% (minimum)
Backlight MTBF	50,000 hours (minimum at 25°C)
Response Time	25 ms (typical)
Display Colors	16 million color display
Viewing Angle (typical)	±80°L/R, ±70°U/D
Video and Power
OSD Controls	Brightness, Contrast, Phase, Clock, Color, H&V position, Auto-tune, Recall
Input Signal	RGB analog 0.7V peak to peak
Video Input Connector	D-sub 15 pin analog VGA
Power Supply	AC/DC 12V power adapter, universal 100-240 Volts
Mechanical and Environment
Operating Temperature	-30~80°C [22~176°F]
Storage Temperature	-30~80°C [-4~176°F]
Humidity	0-95% maximum
Dimensions (WxHxD)	212 x 146 x 62 mm [8.35 x 5.75 x 2.44 inch]
Net Weight	1 Kg [2 lbs]
