24” 1920x1080, LED 1000nits Full-HD TFT Sunlight Readable High Brightness Rugged Chassis/Wall Mount Monitor LCD (Model: YCHW2400HB)

24” 1920x1080, LED 1000nits Full-HD TFT Sunlight Readable  High Brightness Rugged Chassis/Wall Mount Monitor LCD (Model: YCHW2400HB)

24” 1920x1080, LED 1000nits Full-HD TFT Sunlight Readable High Brightness Rugged Chassis/Wall Mount Monitor LCD (Model: YCHW2400HB)

YCHW2400HB
  • Overview
  • Download

Feature:

  • Sunlight Readable.
  • 24” Full-HD TFT LCD with resolution up to 1920x1080.
  • Suitable for military, tablet, ruggedized PC, kiosk, advertising, POS, marline, transportation, gaming, gas pump.


Specifications:

Panel Type 24.0-inch TFT LCD
Screen Diagonal 24.0-inch
Active Display Area (mm) 531.36 (H) x 298.89 (V)
Pixel Pitch (um) 276.75 (per one triad) ×276.75
Number of Pixels 1920(x3) x 1080
Contrast Ratio 3000:1
Display Color 16.7M colors (true 8-bit)
Brightness (cd/m) 1000 cd/m
Viewing Angle(Typ.) 89 / 89 / 89 / 89 ( R/L/U/D)
Signal Connector 15 PIN D-Sub,DVI-D
Power Source DC +12V (+/- 10%)
Power Management VESA DPMS Compliant
Operating Temperature 0 ~ +50 °C
Storage Temperature -20 ~ +60°C
Plug & Play VESA DDC 1/2B
