24" Seperable Style LCD Monitor (Model: RS2400HD2)

24" Seperable Style LCD Monitor (Model: RS2400HD2)

24" Seperable Style LCD Monitor (Model: RS2400HD2)

  • Overview
  • Download
IPS (In-Plane Switching) hard-screen technology.

Panel is the core of LCD monitor, its process technology determines more than 60% quality of LCD monitor.

IPS hard-screen technology is the world's most advanced LCD technology. Compared with the traditional soft-screen LCD, it has faster response time and and more fluent moving pictures.. About traditional soft-screen LCD panel, when view it from the side angle, the color drift phenomenon will emerge. As the IPS screen has a unique structure at the molecular level conversion, therefore, it can reach 178 degrees vertical and horizontal viewing angle, which basically eliminate the “dead angle” visually. Meanwhile, there will not exist the color drift phenomenon like soft-screen LCD, the pictures can be seen clearly even view it from the side angle.

As the most accurate color reproduction display technology till now, IPS hard screen has super high contrast and black-purity, which suitable for subtle display requirements on ultra-high gray.

Split type design
Apart the display (LCD panel) from video & audio processing and master control system, minimize the heat of monitor and make its performance more stable.

More portable
Split type design, minimize the size and weight of monitor to make it more portable.

Easily For Maintenance
If a failure appears, just need to inspect, repair or replace the components built in the bottom case, rather than disassembling the whole unit, which will reduce maintenance costs definitely.

More compatible
Choose “video & audio controllers” with different functions according to  the application requirements at current stage. We just need to buy corresponding “video & audio controller” instead of LCD panel if we want to upgrade the monitor, which will greatly reduce users’ purchasing cost.


More flexible
One “video & audio controller” can work with different size of LCD screen.
One LCD screen can match “video & audio controllers” with different functions as well.

Video/audio signal auxiliary detect function
In order to get accurate luminance and chroma information, RS2400HD2 internally installed high sampling rate brightness waveform, RGB waveform and vector scope. It display the real-time luminance and chroma, which work as photographer's and technician's reference tool to guarantee the record video information within standard luminance range.

Screen protective angle

USD Head phone jack
integrate heat dissipation board


Screen Size 24”
Resolution 1920(H)x1200(V)
Dot Pitch 0.27(H)x0.27(V)mm
Aspect Ratio 16:9 / 4:3 Switchable
Brightness 400cd/m˛
Contrast 1000:1
Response Time 5 ms
Viewing Angle H 178° / V 178°
Voltage Input DC24V
Power  Consumption ≤90W
Installation Desktop or VESA mount
Monitor Size Display Unit:L 584xH 382xD 70 mm
Controller:L 487xH 51.7xD 165.5 mm
Size:L 605xH 435xD 165.5 mm
Total Weight 11.7 kg

Inputs & Functions

Model Function RS2400HD2 Remark
Video input Composite BNCx1 line 1.0 Vp-p±3 dB Negative synchronous
SD-SDI BNCx2 line Brightness waveform RGB waveform Vectorscope HV-DELAY
HD-SDI BNCx2 line Brightness waveform RGB waveform Vectorscope HV-DELAY
VGA D-SUB15x1 line
HDMI HDMIx1 line
Audio Input RCAx1 line(Dual Channels)
Auido montioring Speaker 2x2W(8Ω) Earphone:3.5mm Standard Interface
SDI embedded Audio PPM / UV
Video output Composite BNCx1 line Loopthrough 75ΩAuto termination
SD-SDI BNCx1 line
HD-SDI BNCx1 line
TALLY red/green two colors

Analog Input Spec.

Input Signal Signal Spec. Signal System Standard RS2400HD2
Composite(CVBS) 480/60p NTSC ITU-R BT.601
576/50i PAL ITU-R BT.601
VGA 640*480/60p VGA VESA
800*600/60p SVGA VESA
1024*768/60p XGA VESA
1280*768/60p WXGA VESA
1280*800/60p WXGA VESA
1280*1024/60p SXGA VESA
1440*1050/60p SXGA+ VESA
1680*1050/60p WSXGA VESA
1600*1200/60p UXGA VESA
1920*1200/60p WUXGA VESA

HDMI Input Spec.

Signal Spec. Interface sampling frequency (MHZ) Standard RS2400HD2
640*480/60p 25.200 CEA-861
720*480/60i 27.027 CEA-861
720*480/60p 27.027 CEA-861
720*576/50i 27.000 CEA-861
720*576/50p 27.000 CEA-861
1280*720/50p 74.250 CEA-861
1280*720/60p 74.250 CEA-861
1920*1080/50i 74.250 CEA-861
1920*1080/60i 74.250 CEA-861
1920*1080/24p 74.250 CEA-861
1920*1080/25p 74.250 CEA-861
1920*1080/30p 74.250 CEA-861
1920*1080/50p 148.50 CEA-861
1920*1080/60p 148.50 CEA-861

SDI Input Spec.

SMPT Signal Standard Signal Spec. RS2400HD2
425M-A/B(3G) 1920*1080/50p
274M(HD) 1920*1080/60i
296M(HD) 1280*720/60p
125M(SD) 480/59.94i
ITU-R-BT656 576/50i

RS2400HD2 Functions table

Brightness waveform
RGB waveform
Marks:Safety mark,Center mark,Title frame
Scaling: 16:9,4:3,LETTER BOX,Built-in scan,Overscan ● (unsupport built-in scan) ● (unsupport built-in scan) ● (unsupport built-in scan)
Pixel to Pixel
Color temperature 9300/6500 , adjustable
8 channels audio meter display
UMD function
Red/Green two colors TALLY display (Soft TALLY) (Soft TALLY) (Soft TALLY) (Soft TALLY) (Soft TALLY)
Peaking(peaking level,edge color,edge width adjustable)
False color
Battery checking
Backlight control
Monochrome(BLUE ONLY)

Function Sketch Front View

1 LCD panle
2 Screw nut
3 Bracket
4 Speaker
5 Sharpness / Zoom
6 Saturation
7 Contrast / Volume
8 Brightness / OSD
9 Function key field
10 Controler
11 Headphone jack

Function Sketch Back View

12 Handle
13 DP input
14 DC input
15 Software upgrade interface
16 Protection bar
17 DC output
18 DP output
19 VGA input
20 TALLY signal
21 HDMI input
22 HD/SD-SDI input
23 HD/SD-SDI output
24 Audio input
25 Composite I/O
26 DC 24V power input
27 Power switch
28 VESA mounting hole
