The BAPC2330D2 is a unique product. While your average single display system has its limitations, the BAPC2330D2 comes with two 23”, wideview, HD LCD displays to fulfill the requirements of applications that need more perspective.

With 7-expansion slots design, the BAPC2330D2 is an ideal platform for digital media related applications in the broadcasting market. It can also be configured with many special add-on cards for your unique applications and is also typically used in the military field.

The high contrast ratio optimizes viewing when ambient light or sunlight has become distracting. Optional touch screen allows the BAPC2330D2 to operate without keyboard for quicker operations.

Every unit comes equipped with cooling fans and easy access to its expansion slots for immediate system upgrade or maintenance. With its functional design and rugged construction, the BAPC2330D2 is the most durable and versatile portable platform for your applications.

2x 4K Displays

The BAPC2330D2 is the first every portable workstation with 4K resolution. The dual 4K displays add up for a combined 7680x4320 resolution. It is ideal for many professional works that are in the digital media or broadcasting field, including but not limited to 3D rendering, post-production processes, and professional photography. With this computer, you can now observe new details of your work.

The BAPC2330D2 also comes with the option of having full HD displays. In other words, if 4K resolution is more than you need, you can choose to the 1080p option (1920x1080 resolution).

• Portable platfrom optimized for broadcasting and post-production applications
• 2x 23” 16:9 LED backlite LCD at full HD resolution of 1920x1080
• Multiple PCI-E v2.0 slots for full-length add on cards
• Integrated with the latest Intel® Core™ i7 processors/Dual Xeon® Processors
• 7x 3.5” removable HDD cages for storage capacity

Specifications

Chassis	Material: Aluminum Alloy Color: Black Screen: Dual 23.3’’ LED LCD, 1920x1080 Keyboard: Integrated Qwerty 105-keys with touchpad; Dimension: 15.12" x 23.11" x 9.02" (H x W x D) System Weight: 45lbs Power Supply: 850W PS/2 Other: Padded soft carrying case w/ wheels
System Board	GIGABYTE GA-Z97X-UD5H-BK LGA 1150 Intel Z97 HDMI SATA 6Gb/s USB 3.0 ATX Intel Motherboard
CPU	Intel Core i5-4690K Devil's Canyon Quad-Core 3.5GHz LGA 1150 Intel HD Graphics 4600
CPU Cooler	High Performance Intel LGA 1150 CPU Cooler
Memory	4GB (2 x 2GB) 240-Pin DDR3 SDRAM DDR3 1600 (PC3 12800) BLS2KIT2G3D1609DS1S00
OS Storage	SAMSUNG 850 PRO MZ-7KE256BW 2.5" 256GB SATA III 3-D Vertical Internal Solid State Drive (SSD)
Additional Storage	WD Re WD1003FBYZ 1TB 7200 RPM 64MB Cache SATA 6.0Gb/s 3.5" Enterprise Internal Hard Drive Bare Drive
Optical Drive	Panasonic UJ-265 Slim 6X Blu-ray Writer SATA Slot Load
Operating System	Windows 7 32 Bit Professional
Video controller	EVGA 04G-P4-3966-KR GeForce GTX 960 4GB 128-Bit GDDR5 PCI Express 3.0 x16 SLI Support SuperSC ACX 2.0+ Video Card
Expansion Slots Open	PCI Express 3.0 x16: 2 slots (single @ x16, dual @ x8/x8, triple @ x8/x4/x4) PCI Express x1: 1 PCI Slots: 2
Rear I/O Plate	LAN Chipset: Intel i217V & Qualcomm Atheros Killer E2201 Max LAN Speed: Dual 10/100/1000 Mbps PS2 Port: 1 xPS2 KB and Mouse Port Video Ports: 1x DVI-D, 1x VGA, 1x HDMI USB 3.0: 6 USB 1.1/2.0: 2 Audio: Realtek ALC1150 Chipset, 7.1 Channels, 1x Optical, 5 Ports
