23" Industrial Touch LCD Monitor w/ USB Controller (Model:CCH2300-TRB )

23" Wide-Screen Industrial Grade LCD Integrated Touch Screen w/ USB Controller(Model:CCH2300-TRB )

23" Wide-Screen Industrial Grade LCD Integrated Touch Screen w/ USB Controller(Model:CCH2300-TRB )

CCH2300-TRB
  • Overview
  • Download
Product discontinues. Contact us at Info@iTechLCD.com for replace items. Features:

(This product is Non-Returnable)

Wide-screen Industrial - Grade 23.0" integrated Touch Screen LCD monitor designed for desktop and VESA arm-mount applications.

It utilizes a 23.0? (16x9)widescreen diagonal color TFT LCD as Industrial grade display and a integrated resistive touch screen as input device. Touch screen communication to CPU is RS232 or USB.

Industrial LCD Display Specifications
General

Product Type
LCD TV
Technology
TFT Active Matrix
Display size
Diagonal: 22.9" widescreen
Width
22.8 in
Depth 8.3 in
Weight
22 lbs
Video System
  Resolution 1280 x 1024 @ 60Hz
  Image contrast Ratio 500:1
  Pixel Pitch 0.39 mm
  Pixel Response time 25 ms
  Viewing angle 170 degrees
  Brightness 500 cd/m2
Audio System

Output mode
Stereo
Television Features
  Miscellaneous compliant standards Stereo - integrated
  Additional features On-screen menu
Tuner/Channel Details
  TV tuner multi-channel preview Split screen, Picture- in- picture (PIP), Picture-on-picture (POP)
Remote Control
  Remote Control Infrared
Connections/Cables/Slots
  Input/Output connections 1 x DVI- Digital (24 pin digital DVI) - Rear,
1 x VGA input (15 pin HD D- Sub (HD- 15)) - Rear,
2 x Component video input (RCA phono x 3) - Rear,
1 x Audio line- in (Mini- phone stereo 3. 5 mm) - Rear,
1 x Composite video input (RCA phono) - Rear,
1 x S- Video input (4 pin mini- DIN) - Rear,
3 x Audio line- in (RCA phono x 2) - Rear,
1 x Audio line- out (RCA phono x 2) - Rear,
2 x Speakers output (RCA phono x 2) - Rear,
1 x Subwoofer output (RCA phono) - Rear
  Cables Included 1 x VGA cable, 1 x Audio cable
Power
  Power device Power supply - External
  Voltage required 50/60 Hz
  Power consumption operational 120 Watt
  Operational power consumption 5 Watt
Shipping Dimensions
  Width(Shipping) 26.6 in
  Depth(Shipping) 10.5 in
  Height (Shipping) 22.9 in
  Weight (Shipping) 30.9 lbs


Touch Screen Typical Specifications
COMMERCIAL Touch Screen  INDUSTRIAL Touch Screen MILITARY Touch Screen
Mechanical
 Actuation Force* 20-500 grams 20-500 grams 20-500 grams
 Actuation Travel 0.05 mm 0.05 mm 0.05 mm
 Thickness (w/o sup.) 0.50 mm 0.50 mm 0.50 mm
 Thickness (w/sup.) 2 mm (min) 2 mm (min) 2 mm (min)
 Mechanical Life 36 million + 36 million + 36 million +
 Electrical
Contact Resistance:
     Open 20 Meg Ohm 20 Meg Ohm 20 Meg Ohm
     Close 10-30 K-Ohm 10-30 K-Ohm 10-30 K-Ohm
Operating Voltage 5 Volts 5 Volts 5 Volts
Operating Current 5 Micro Amp 5 Micro Amp 5 Micro Amp
ESD Shield 7 KV Min 7 KV Min 7 KV Min
Optical
 Light Transmissivity:
 @ 550 Nano Meters  82%-83% 82%-83% 82%-83%
Environmental
 Temperature
        Operating &
Non-Operating:
0 to 35°C (32° to 95°F) -10° to 55°C (14° to 131°F) -40° to 85°C (-40° to 185°F)
 Altitude
         Operating &
Non-Operating:
12,000 meters 12,000 meters 12,000 meters
 Vibration
  0.7G @ 15 Hz 0.7G @ 15 Hz 0.7G @ 15 Hz
1.3G @ 25 Hz 1.3G @ 25 Hz 1.3G @ 25 Hz
3G @ 55 Hz 3G @ 55 Hz 3G @ 5 Hz
 Shock
  30G for 11 Mil. Sec. 30G for 11 Mil. Sec. 30G for 11 Mil. Sec.
 * Using a .375 inch diameter RTV tip.
Installation Manual
Windows Mac Linux

Windows 2K/XP

Windows 9X/ME

Mac

Windows NT 4.0

DOS

Linux

Windows CE
Click for download driver
