180ES: Avocent 1 user, 8 systems, OutLook console switch

180ES: Avocent 180ES 1 user, 8 systems, OutLook console switch

180ES: Avocent 180ES 1 user, 8 systems, OutLook console switch

180ES
  • Overview
  • Specifications
  • Download

This product has been discontinued

Please click here for replacement product

Features and Benefits

  • Controls up to 128 computers from one console
  • Multi-Language Support
  • Innovative locking cables
  • Support for multiple platforms
  • New Oscar GUI
  • Switch Setting Security
  • Non-intrusive out of band operation
  • Flash memory for easy upgrade
  • Serial Port (RS-232)
  • Microsoft DDc Plug & Play compliant
  • 1600 x 1280 video resolution
  • 1U, EIA Rack mountable
  • Automatic System Restart
Specifications
Mechanical
Height
1.75 in. (4.5 cm)
Width
17.0 in. (43.2 cm)
Depth
8.0 in. (20.3 cm)
Weight
6.8 lbs. (3.48 kg)
Environmental
Operating Temp
32 to 158°F (0 to 70°C)
Storage Temp
-40 to 185°F (-4 to 85°C)
Power
Operating Voltage
100 to 240 VAC
Power Frequency
50 - 60 Hz
Input

Supported Hardware
Computer
RISC System 6000TM , PC, Apple MacIntosh, HP9000 (with adapters)
Monitors
SVGA, VGA, XGA, resolution 1600x1200 @ 72 Hz
Peripherals
PS/2 keyboard, PS/2 mouse, IntelliMouse (PS/2 only)
Standards
Approved Agency
FCC-A, cUL, UL, TUV/GS, CE.

Order Detail Part Number
1 user, 8 systems, OutLook console switch 180ES

Cables Part Number
Molded keyboard, monitor and mouse cable - 3 feet CO-0332
Single Sheath keyboard monitor and mouse cable - 7 feet CO-0732
Single Sheath keyboard monitor and mouse cable - 12 feet CO-1232
Molded keyboard, monitor and mouse cable - 20 feet CO-2032
Molded keyboard monitor and mouse cable - 40 feet CO-4032
KVM - extension cable set (switch to console) - 7 feet CZ-0720
KVM - extension cable set (switch to console) - 12 feet CZ-1220
