10.4" High Quality Panel, 1024 x 768 resolution, IntelŽAtom D2550 1.86 GHz Processor. Wide range operating Temp (-25 to 55 deg.) (Model: WRDC0140XCT)

10.4" High Quality Panel, 1024 x 768 resolution, IntelŽAtom D2550 1.86 GHz Processor. Wide range operating Temp (-25 to 55 deg.) (Model: WRDC0140XCT)

10.4" High Quality Panel, 1024 x 768 resolution, IntelŽAtom D2550 1.86 GHz Processor. Wide range operating Temp (-25 to 55 deg.) (Model: WRDC0140XCT)

WRDC0140XCT
  • Overview
  • Download

Features:

  • IntelŽAtom D2550 1.86 GHz Processor
  • High Quality 10.4" Panel, 1024 x 768 resolution
  • 10 user-defined function keys on the bezel
  • Ignition on/off delay for power management
  • Customized software to control ignition on/off delay
  • Wide range input voltage 6-60 Volt
  • Wide range operating temperature (-25 to 55 deg. )
  • Optional GPS, 3G / WLAN(Either one). Digital IO / Canbus (Either one)
  • Optional 6-60V DC Input, and Optional for Ignition On/Off delay
  • Compliance with EN50155


Specifications:


Display
Size 10.4''
Resolution (pixels) 1024 x 768
Number of Colors 16.2M ( 6 bits+FRC )
Brightness (cd/m2) 350 (typ.)
Contrast Ratio 1200 :1 (typ.)
Viewing Angle -88~88 (H) ; -88~88 (V)
Active Area 201.4 (H) x 157.8 (V)
Touch (optional) 5 Wire Resistive / IR Touch
System
Processor IntelŽ Atom D2550 1.86 GHz Processor
Chipset IntelŽ NM10 Chipset
BIOS AMI 16Mbit Flash
Memory 1xDDR3 800/1066 MHz SO-DIMM Max. 4GB
Ethernet Broadcom BCM57780 GbE Controller
Storage 2.5" SSD
Expansion Slot 1 x Mini PCIe slot (for wireless module)
Wireless (Optional) 1 x Mini PCIe slot (for SATA SSD)
Input / Output
Back Panel I/O Port 2 x RJ-45 (10/100/1000 Mbps)
1 x VGA(DB-15)
1 x DC-in Jack (Phoenix type)
2 x USB 2.0
1 x RS232/422/485, 1 x RS232
WLAN antenna SMA in top (Optional)
Environment
Operating Temperature -25 deg.C to 55 deg.C
Storage Temperature -30 deg.C to 70 deg.C
Humidity 10% to 95% (non condensing)
Shock Operating:30g for 18ms, 300m/s˛
Vibration Operating: 1.60/1.96/2.18 g rms for XYZ / 5-500Hz
Power Input 9~36V DC in (Phoenix type)
Optional 6-60V DC in, with Ignition On/Off delay
Power Consumption 30W typ.
Mechanical
Dimensions (W x L x H) 315 mm x 250 mm x 67 mm
Approximate Weight 3.3 kg*
Driver OS Support Windows 7 embedded / Windows XP embedded
Certifications CE/FCC ClassB, MIL810F / IEC60068-2-27 for Vibration / Shock
Packing List ID30 Atom SBC User’s Manual
User’s Manual
(ID30) SBC Manual & Driver CD
Product Optional Items
Mounting Bracket and Kits One robust bracket with locking handle
(Can adjust from -5 deg.C to 90 deg.C)
Sunlight Readable N/A
Anti-reflective Glass 3mm (Replace touch)
WLAN Mini PCIe base Wireless LAN card with SMA antenna
GPS USB interface, MTK chip
Digital IO / Canbus Either one
