10.4” Industrial Monitor Rugged Cast Aluminum Enclosure with optional touchscreen (Model: UCH1040IP)

10.4” Industrial Monitor Rugged Cast Aluminum Enclosure with optional touchscreen (Model: UCH1040IP)
  • Front View
  • Front View
  • Back View
  • Right Side View
  • Left Side View

10.4” Industrial Monitor Rugged Cast Aluminum Enclosure with optional touchscreen (Model: UCH1040IP)

UCH1040IP
  • Overview
  • Specifications
  • Download
Product discontinues. Contact us at Info@iTechLCD.com for replacement item.

Features

  • Extreme rugged cast aluminum enclosure
  • Adheres to NEMA 4X/IP65 specifications
  • Bright LCD sizes include 10.4, 12.1, 15.0”,17.0”, and 19.0”
  • Optional Resistive, Capacitive or Infrared Touch Screen
  • USB or Serial Touch Screen interface
  • Standard VGA, S-Video, or Composite Video Ports
  • Stand Alone Rugged LCD Monitor
  • Easy Control front panel OSD – Brightness and Contrast
  • Auto video resolution resizing
  • UCH Series monitors are ideal for high dust or waterproof environments, such as foundries, steel plants, food processors, and hospitals.

Product Overview

iTechLCD's Innovative stand alone UCH Series Industrial sealed 10.4, 12.1, 15.0”,17.0”, and 19.0” provides a perfect solution for any industrial monitor that needs to be wall mounted, desk mounted, or arm mounted.

Front Panel Control

The Easy Control OSD (On Screen Display) keypad gives the ability to adjust brightness, contrast, power, and toggle from composite video to PC monitor mode with one key. Using Easy Control OSD lock out mode all functions are locked out to the user, even power.

Connectivity

Standard VGA, Composite Video, or S-Video input. Touch screen interface RS-232 or USB

Touch Screen Options

The unit comes standard with Plexiglas, but can be ordered with a rugged Resistive, Capacitive, or Infrared Touch Screen.

Outdoor Display Option

In addition, a bright 10.4”, 12.1” 15”, 17”, and 19” TFT color display simplifies user interaction with touch screen capabilities and color graphics. A daylight readable display option is also available to allow easier viewing in direct sunlight.

Rugged, Tested Design

The UCH Series has a rugged cast aluminum housing that meets the IP65 rating. The UCH Series can withstand extreme harsh environments, dust, moisture, and extreme temperatures. The UCH Series has been used in outdoor, abrasive, and wash down environments. It is truly a rugged device.

Mounting

  • Wall Mount Brackets
  • VESA 100mm X 100mm Mounting Plate
  • Keyboard Mounting arms for Wall Mount applications
  • Desk Stand





Technical Specifications
Enclosure: Sealed Rugged Aluminum Enclosure, adheres to NEMA 4X
Dimensions:  UCH1040IP:   11.125" (H) x 13.250" (W) x 2.876" (D)
UCH1200IP:   12.500" (H) x 14.875" (W) x 2.876" (D)
UCH1500IP:   14.000" (H) x 17.000" (W) x 2.876" (D)
UCH1700IP:   15.750" (H) x 18.500" (W) x 3.189" (D)
UCH1900IP:   17.000" (H) x 20.000" (W) x 3.311" (D)
Resolution / NIT (call for high bright\outdoor options)
UCH1040IP - 10.0” LCD: SVGA - 800x600 - 250 NIT
UCH1200IP - 12.1” LCD: SVGA - 800x600 - 400 NIT
UCH1500IP - 15.0” LCD: XVGA - 1024x768 - 300 NIT
UCH1700IP - 17.0” LCD: SXGA - 1280x1024 - 300 NIT
UCH1900IP - 19.0” LCD: SXGA - 1280x1024 - 270 NIT
Non-OperatingTemperature: -20º to 60º C (all monitors)
Operating Temperature: 0º to 50º C (all monitors)
Operating Shock: 10g, 11ms, 1/2 sine
Operating Vibration: .41g, 3-500 Hz
Video Interface: DB15 VGA Female connector, Composite Video (NTSC, PAL), S-Video interface
Touch Screen Interface: DB9 Serial Female or USB connector
Mounting Options: Wall Mount Brackets, Desk stand or Pendent Arm (pole or wall mount)

Made in the USA Other accessories are available upon request.
Specification subject to change without notice.
